Galli & Cassina

Overview

Galli & Cassina plug valves deliver zero-leakage, bubble-tight shutoff for demanding oil & gas and pipeline service.

Specifications

• API 6D standard
• NACE MR0175 compliant
• A352 LCC body/plug — suitable for -50° F applications
• Locking gears/levers as standard
• Fire tested to API 6FA
• ISO 15848-1 compliant for fugitive emissions
• Case-hardened plug with PTFE low-friction treatment to reduce torque
• Offered in multiple patterns: Short, Venturi, Regular, and Full Port
• Zero-leakage bubble-tight shutoff for pressures up to API 10K
• Available with hard-facing overlays, electroless nickel plating, and tungsten-carbide coating

Ideal Applications

• Throttling
• Blowdown
• Bypass
• Launcher/Receiver
• Storage

Applications & Benefits

The case-hardened, PTFE-treated plug lowers operating torque while delivering bubble-tight, zero-leakage shutoff up to API 10K pressures. API 6D design, API 6FA fire testing, NACE MR0175 compliance, and ISO 15848-1 fugitive-emissions certification make these plug valves a strong fit for regulated oil & gas and pipeline duties — including throttling, blowdown, bypass, launcher/receiver, and storage service. The A352 LCC body supports low-temperature operation to -50° F, and optional hard-facing, nickel plating, or tungsten-carbide coatings extend wear life in aggressive media.
